129" X 59" HOLZHER ECO-MASTER 7120 3-AXIS CNC ROUTER

129" X 59" HOLZHER ECO-MASTER 7120 3-AXIS CNC ROUTER General Specifications Displacement Travel (X-Axis) 129" Displacement Travel (Y-Axis) 58.9" Displacement Travel (Z-Axis) 12.6" Max. Panel Thickness 5.11" Longitudinal Speed (Max.) 75 m/min Transversal speed (Max.) 75 m/min Z-Axis Speed 30 m/min Drill Spindle Speed 4400 RPM Vertical Drill Length 70mm x 10mm shank (7) RH and (7)LH Horizontal Drill Length 57mm x 10mm Shank (2) RH and (2) LH Saw Blade Dimensions 150 mm max. dia. w/30mm bore 2.6- 3.5mm kerf Standard Electric supply 220-242V 60Hz Dust Extraction (Min.) 5,300 m/h Dust Collection port sizes 1-250mm Extraction speed 30 m/s Operating Air Pressure 6-7 Bar 90-100 PSI Motor Specifications Not Available Equipped With PC Based CNC Control with Software Twin Cam 12 HP Electro Spindle 1000-24,000 RPM HSK63 12 Vacuum Pods & Pop-up Pins 14 Vertical independent Spindle -Boring Block, 10 Pos. X-Axis, 4 Pos. Y-Axis 150mm Saw on Boring Block & Floor Safty Matts Gardner Denver 2BL2101-2AH50 Vacuum Pump Serial Number 163/0-205 Year 2002 Location PROSPECT HEIGHTS, IL Gray Machinery [email protected] 847-537-7700
