Tornos Deco 20 CNC Swiss Lathe m/c #394444

Visit us at www.automatics.com Equipped with (to be confirmed by buyer): Robobar SSF532 Magazine Bar Loader s/n41-111042 Chip Conveyor Mayfran International Chip Tote s/n 01M4587 C Axis Main and Sub Live Spindles on S-1 (Main Z1) S-2 (Live Tooling X2-Y2) S-3 (Front Working X3, Z3) S-4 (Pick-off Spindle Y4, Z4, X4) S-5 (Back Working Y4, Z4, X4) Misc tool holders Square Tool Holders Drill Sleeve Holders Live Drilling / Milling Attachments Approx Hours 34,000 General specification as per OEM Brochure for Tornos Deco 20 Control: Fanuc PNC-Deco Bar capacity: 20 mm Max number of axes: 10 Headstock: spindle speed: 0 - 10,000 rpm motor power: 3.7kw/5.7 hp spindle indexing: 0.1 degree Main spindle: spindle speed: 0 - 8,000 rpm motor power: 1.5kw/2.2 hp Endworking: number of tools: 4 spindle speed: 0 - 6,000 rpm motor power: 1.5kw/2.2 hp Sub-spindle / counter-operation: max clamping diameter: 25.4 mm spindle speed: 0 - 10,000 rpm max number of counter operations: 7 fixed and driven spindles: 4 fixed/3 driven spindle speed: 0 - 8,000 rpm motor power: 1.5kw/2.2 hp Electrics: 480 volt
