Thermal Stress Analysis in Femap

In this video we will be using a model of a mounting plate that has already been created. The analysis process includes: Creating an ambient temperature body load as well as nodal temperatures. Analyzing the model with NX Nastran’s Steady-State Heat Transfer Solution Method. Creating a load from the temperature results, as well as, defining pinned constraints. Analyzing the model with NX Nastran’s Static Solution Method and then post processing the stress results using FEMAP’s contour capabilities. For more information visit http://www.panso.in or write a mail to [email protected]
