The ultimate LIDL glider RC conversion into an A-10 Warthog - Build Video

The ultimate LIDL glider RC conversion into an A-10 Warthog - Build VideoУ вашего броузера проблема в совместимости с HTML5
I still had some of the LIDL chuck gliders in the corner of my workshop, waiting for a crazy RC conversion. But what to do with them? When scanning through the different possibilities, I came across the A-10 Warthog. The shape of the LIDL glider wasn't too far away, but certainly it would need some modifications... so there I had my challenge: Build an A-10 Warthog from a LIDL chuck glider. Link to the flight video of the LIDL A-10 Warthog: https://youtu.be/3T8MGWO6xxw Specs: Basic plane: LIDL Playtive XL Glider Motor: 2x Graupner Ultra 2806 2300kv brushless motor ESC: 2x Graupner Brushless Control + T 18 XT-60 Battery: 3S / 1600 mAh Servos: 3x Emax ES08D II Props: 2x HQ 3-blade 5x4,3 Wing span: 860mm Length: 680mm Weight: 700g Top Speed: 90km/h Flight time: approx. 4:30 min Material: Carbon fiber tubes 5x4mm for wing spar and rear fuselage reinforcement Carbon fiber rods 4x1mm for front fuselage reinforcement Flite Test Foamboard for engine nacelles XPS foam for canopy and the filler pieces of the original wing cut-out Epoxy resin Fiberglass fabric: 80g/m2 Screed glue: fermacell Estrich Kleber (for glueing XPS foam and for glueing the wing to the fuselage) - Be sure to carefully sand the surface of the foam before glueing! Hot glue Canopy lock: Pichler extron Kabinenhaubenverriegelung PLA filament: DruckerRhino PLA Spray paint: Dupli Color Platinum Free plan: https://drive.google.com/file/d/1KkMtCPAyDJJiDfZnhPGTnhiQYLxQ0dJd/view?usp=sharing STL file for engine nacelle: https://drive.google.com/file/d/1T32XbfBhZJzAarAm8enYn-Jerw98IV4O/view?usp=sharing STL file for horizontal stabilizer bracket (upper): https://drive.google.com/file/d/1WZmIlxWWASq4e0ncbrqhtjSSMXhoBlKU/view?usp=sharing STL file for horizontal stabilizer bracket (lower): https://drive.google.com/file/d/1HGJYdLHp0Lomrvta8oQshWLcFIUi81qL/view?usp=sharing FT Mighty Mini Power Pod (MT2206_16x19mm_Standard) by AustinSaintAubin: https://www.thingiverse.com/thing:1096211/files 3D Printer: Prusa i3 Mk3 Cameras: Sony HDR-CX730 GoPro Hero 4 black DJI Mavic Air Music: Fig Leaf Times Two by Kevin MacLeod https://incompetech.com/ Promoted by MrSnooze https://youtu.be/OD_wCefPp_A Creative Commons CC BY 3.0 https://goo.gl/Yibru5 Track; We Are The Empty - Coffin Skies Music provided by FlyingTunes Watch; https://youtu.be/X6F2gyGAoAc
