MODULAR PULL CLAMPING SYSTEM -IMAO CORPORATION-

New Style of Pull Clamps! MODULAR PULL CLAMPING SYSTEM Perfect for Machining from 5-face! For improvement of workholding with 5-axis or 5-face machining! IMAO'S MODULAR PULL CLAMPING SYSTEMS will be the solution! The cylindrical body prevents interference with tools By pulling down the workpiece from bottom 5-face workholding is possible! In comparison with the conventional clamping methods, You are accessible to the workpiece without tool interference! 3 Sizes in 3 Types, 9 Options in total are available Flanged Type Single Type Double Type Attach tapered clamping screws on workpiece Set on MODULAR PULL CLAMPING SYSTEM Simply tighten hex locking screws on side of the bodies with hex wrench You are ready to machine your workpiece! Precise dual-contact of tapered surfaces provide the excellent locating repeatability at 5μm! In combination with TAPERED CLAMPING SCREWS, The height adjustment is easy By simple coupling of the CLAMPING MODULES! The simple workholding provides you Shorter fixture preparation time even with complexed shape workpieces! Application Examples Easy height adjustment by simple coupling of the clamping modules. For example, this system is ideal for part machining Application Examples Mold Machining Versatile fixture is possible by standardizing the hole positions for clamping screws. Or mold machining! Using MODULAR PULL CLAMPING SYSTEMS to multiple applications Lowers fixturing cost! IMAO's MODULAR PULL CLAMPING SYSTEM Provides simple fixture preparation And enables 5-face machining Modular Pull Clamping System The best choice for 5 axis machining!
