LB3256 (BK8000L) bluetooth module from ICStation.com, used with PAM8403

In this video I show you a BK8000L based LB3256 bluetooth module, which can be used to make portable bluetooth speakers. As a test I went rogue and did something that all the information I was able to find adviced not to do: used PAM8403 amplifier. even though this module was designed to be used with amplifiers that have differential inputs. To reduce the gain, I used 47kOhm resistor instead of 10kOhm that is usually used in cheap PAM8403 modules. In this case results were amazing! With different power source, speaker, PCB layout etc things might be different, so I suggest getting an amplifier with differential inputs. EagleCAD library for this module: https://github.com/hugatry/LB3256-lbr This module was given to me by ICStation. ICStation also gave a coupon to share with you: COUPON: Code: hhics Discount Amount: 18% off Max Use: 1 (one for per user) Amount Limit: 100 "DC 2.8-4.2V LB3256 Bluetooth Stereo Module Audio Transceiver" (Check up-to-date price from their website): http://www.icstation.com/lb3256-bluetooth-stereo-module-audio-transceiver-p-9100.html ICStation has great selection of modules, components and other items and they are constantly adding new products, so be sure to check new arrivals at http://www.icstation.com/products_new.php every now and then. I look forward to doing more videos about their products in the future! If you liked the video, please show it and hit the Like-button! Check out my other videos: https://www.youtube.com/user/hugatry/videos Subscribe: https://www.youtube.com/user/hugatry?sub_confirmation=1
