How to configure DHCP address reservation on TP Link Router

DHCP ADDRESS RESERVATION IN ROUTER WHERE YOU CAN LEARN TO BIND A IP ADDRESS WITH A MAC ADDRESS. Address Reservation Help When you specify a reserved IP address for a PC in the LAN, that PC will always receive the same IP address each time when it accesses the DHCP server. Reserved IP addresses could be assigned to servers that require permanent IP settings. MAC Address - The MAC Address of the PC that you want to reserve an IP address for. Reserved IP Address - The IP address that the Device reserved. Status - It shows whether the entry is enabled or not Modify - To modify or delete an existing entry. To Reserve IP Addresses, you can follow these steps: Enter the MAC Address (The format for the MAC Address is XX-XX-XX-XX-XX-XX) and the IP address in dotted-decimal notation of the computer you wish to add. Click the Save button. To modify a Reserved IP Address, you can follow these steps: Select the reserved address entry as you desired, modify it. If you wish to delete the entry, click the Delete link of the entry. Click the Save button. Click the Add New... button to add a new Address Reservation entry. Click the Enable All button to enable all the entries in the table. Click the Disable All button to disable all the entries in the table. Click the Delete All button to delete all the entries in the table. Click the Next button to go to the next page, or click the Previous button return to the previous page. Note: The changes will not take effect until the Device reboots. https://youtube.com/subhojitdp ----- YOUTUBE LINK https://facebook.com/infotech.dp ----- FACEBOOK LINK Are you looking for these below questions? Then this tutorial is for you friends. How to configure dhcp address reservation? How to bind mac address and ip address together for dhcp address reservation? DHCP Address Reservation in Router? tp link login ip address how to configure tp link router with static ip tp link router ip default password tp link login address tp link ip address default tp link ip address not working my tp link ip address tp link assign static ip
