How a VFD or variable frequency drive works - Technical animation

Describes the functioning of VFD or variable frequency drive. Other names for this are frequency converter, AC drive converter, etc. - Comments are welcome! From the content: 0:00 Introduction 0:42 Block diagramm of its main componentes and their function 1:16 Building the output signal by PWM 1:32 Building a 3 phase signal 1:53 Controlling the torque 1:20 Controlling the speed 2:19 Parameter Boost and ramp 3:05 Technical implementation of the component DC/AC converter Our Engineering Tutorial Video Channel. Topics covered: Automation, Electrical, Robotics, Hydraulics, Pneumatics, Our official website: http://learnchannel-TV.com Facebook: https://www.facebook.com/Learnchannel-TVcom-1744238709207184/ Contact: [email protected]
