Hacking Neo Geo Mini Japanese version + Resizing all Artwork Images at one command, part1

neogeo-mini-hack https://yadi.sk/d/r2ZOm3iJd78vKg unzip it all. Open 4 srews in the botton of the neogeo-mini Plug second controller C-cable in and to PC. Hold button on the system board, press Neo Geo Mini Power button in the back. Plug second controller C-cable in and to PC. then open "device manager" and updated the usb driver, Look for Unknow device. And install Update drive. Browse your computer folder for the driver. #########Neo Geo mini hack######### Open “device manager” then press tiny button underneath the Neo Geo mini which is at the bottom of the plate which you remove. Hold the button then turn Neo Geo on. You should get a connection sound once you plug the USB C connection to player two on the right side. Then plug the USB to computer. Your Device Manager should said “Action USB 2.0 (HS) WinUSB Device” below the selection call “Universal Serial Bus controllers”. If you get this far then you’re good if not maybe the cable or software driver need to be updated. Please see my video again. Now the next step. Start program call “WinImage” click open and selected and browse for a folder c:\NeoGeo-Mini-Hack\Burning file\vendeor.img this file can’t be bigger the 2,740,474 KB if the size are larger then this number after you notified your image it will not burn. Make sure you save the image after you did same change to it and close WinImage. Third step or last step to burn it Go to folder call “1.05.02” and open file call”MainApp.exe” once you open this program on top left should said “1 USB Device Detected ( 0 UDisk, 1 ADFU)” on green top bar of the program. If you do see this then so far so good. If not then your cable or driver issue. Now click on small button that have two arrows on the bottom in the middle of the screen which also said “Replace Firmware” look for “c:\NeoGeo-Mini-Hack\Burning file\linux_gl5201_vlc_v6_rgb.fw” Then click “replace” then Make sure you click on Top left corner “Multiple Partition Image” put check on it before click “ DOWN” button hope this help. ############################### Actions Pad Product Tool v1.05 https://yadi.sk/d/U1rlJxJIFmKx5 https://en.freedownloadmanager.org/users-choice/Pad_Product_Tool_V1.05_.rar.html open "MainApp" Button of screen will show Ready Click on "Down", Choice it then click "replace" \Neogeo-mini-hack\burning file\linux_gl5201_vlc_v6_rgb.fw --------------------Resize all the images at one time----------- http://www.imagemagick.org/script/download.php Scroll until you see "Windows Binary Release" Version HTTP FTP Description "ImageMagick-7.0.8-47-Q16-x64-dll.exe" cmd mogrify -resize 114x78! *.png for LCD mogrify -resize 260x226! *.png for Tv ---------------------------------------------------- access the image https://softfamous.com/winimage/ G:\NeoGeo-mini-Hack\321a181651af3e14c0f2-264e569afc3eb242d452f238cf9eb64002e95309\WinImage-KeyGen.html Johnny Liu Registration Code 15D0672F 9CC6743 7D16745 17D46747 18D16DB2 26CF6D80 1BD16DB2 EDC6D83 29DC6D83 ================================================ The download URL is https://yadi.sk/d/r2ZOm3iJd78vKg There will be • "1.05.02.rar" is a burning tool • "Burning file.rar" is the burning file • "Driver.tar.bz2" is the driver 1. Need PC, Power cable to Neo Geo Mini Hack, another USB C to USB; One end to Neo Geo Port 2 and other end to PC.
