Design Documentation with Draftsman | Altium Designer 19 Essentials | Module 26

In this module we will tackle generating graphical documents for Board Design Production using Draftsman. We will demonstrate how to add fabrication drawing and assembly drawing in the project document. Module Highlights: 01:11 Adding a Draftsman Document to the Project 02:40 Defining the Project Parameters 04:15 Demonstrating Mouse and Keyboard Gestures for Panning and Zooming the Project Editor 05:00 Exploring Objects that can be added in the Project Editor Under Place menu 05:35 Adding the Assembly View in the Project Document 06:37 Utilizing the Detail View to enlarge Specific Areas 07:26 Adding Dimension to the Project Design 08:10 Adding the Layer Stack Legend and BOM Tables 09:30 Placing the Fabrication Views in the Project Document 10:20 Placing Drill Drawing in the Project Document 11:00 Demonstrating How Changes are Applied in the Draftsman Document when the PCB Design is Updated Learn more about the newest release at: https://www.altium.com/altium-designer/whats-new Follow Altium on Twitter: https://twitter.com/altium Follow Altium on Linkedin: https://www.linkedin.com/company/altium/ Follow Altium on Facebook: https://www.facebook.com/AltiumOfficial/ Subscribe to our channel and remember to LIKE and SHARE.
