BC-216 16 channels Madrix software artnet to DMX SPI WS2812 WS2811 WS2801

Feature Function: 1. With LCD display and built-in WEB SERVER setting interface, easy operation. 2. Support Ethernet DMX protocal ArtNet and E1.31, can be expanded to other protocols. 3. Converting the Artnet signal into SPI signal, 16 channels SPI(TTL) signal output, up to 5440 pixels control. 4. Converting the Artnet signal into DMX signal, 2 channels DMX512 signal Output at the same time, convenient for the connection of different types LED lamp. 5. Support various LED driving IC, flexible control. 6. Support online firmware upgrade. 7. Adopt DIP plug-in design for the easily-worn parts, Users can repair the damage caused by worng wiring or short circuit 8. Built-in test mode, using a networking interface with indicator light, work status is clear when at a glance. 9. Widely used for large high-density pixel light project. Such as panel lights, construction's contour lamp,etc. BC-216 16 channels Madrix software artnet to DMX SPI WS2812 WS2811 WS2801 pixel led ethernet controller Specification : Model BC-216 Working Voltage DC5V-24V Output Current 3A*16 channels (Built-in 5A fuse) Input Ethernet control protocol Artnet, E1.31 Output Control IC 6803/ 8806/ 2811/ 2801/ 3001/ 9813/ 1814/ 6812 selectable Control Pixels RGB: 340 Pixels*16CH RGBW: 256 Pixels*16CH Output DMX512 Two port (2*512 Channels) Working Temp -20~55 Product Dimension L258*W145*H41 (mm) Weight (G.W.) 1100g BC-216 16 channels Madrix software artnet to DMX SPI WS2812 WS2811 WS2801 pixel led ethernet controller Control ICs type: IC Type Compatible ICs Type 2811 TM1803, TM1804, TM1809, TM1812, UCS1903, UCS1909, UCS1912, UCS2903, UCS2909, UCS2912, WS2811, WS2812B, SM16703P, GS8206, APA102 etc. RGB 2801 WS2801, WS2803, etc. 6803 LPD6803, LPD1101, D705, UCS6909, UCS6912 etc. 3001 TLS3001, TLS3002 etc. 8806 LPD8803, LPD8806, LPD8809, LPD8812 etc. 9813 P9813 etc. TM1814 TM1814 etc. RGBW SK6812 SK6812, SK6822, UCS2904, P9412 etc. BUY IT NOW:
