Arduino Current Meter, Voltage Meter Circuit. DIY Multimeter
У вашего броузера проблема в совместимости с HTML5
How to make current and voltage meter with Arduino Nano.
How to measure current with Arduino.
How to measure voltage with arduino.
How to measure watt with gauge.
Voltage measurement: 7-24V
Max. current measurement : 20A
Thanks For Watching And Please don't Forget To Like, Share & Subscribe For More Awesome Videos.
KendinYap Channel https://www.youtube.com/channel/UCgjJGE17yfovAvWUzEJFENA
Circuit diagram and code: http://bit.ly/39zTyIZ
Arduino Nano: https://www.banggood.com/custlink/DDKvCLIBk0
0.96 inc Oled Screen : https://www.banggood.com/custlink/D3mGpTMTGW
Necessary Materials:
Arduino Nano
0.96 inc Oled
ACS714 20A Current Sensor
5x5 cm PCB Board
UF4007 Diode
R1 Resistor 10K
R2 Resistor 1.5K
78M05 Regulator
0.1uF Capacitor
0.33uF Capacitor
