ANSYS 17 - Linear Buckling I-Beam Tutorial

ANSYS Wokbench v17.0 tutorial for the linear buckling of an I-beam. We will go over how to create line bodys and assign built in cross-sections. We will then setup our loads and boundary conditions to solve for the difference mode shape results from the buckling of the I-Beam. We will also go over how to display the mode shape animation, as well as retrieving the direct stress results. Links: 1) Excel File Download: https://goo.gl/Sqd0lU 2) http://www.engineeringtoolbox.com/euler-column-formula-d_1813.html 3) http://sketchup.engineeringtoolbox.com/aluminum-i-beams-c_1.html
