2017 Makino A51NX

2017 Makino A-51NX Specifications: Pallet: 15.7" x 15.7" X: 22.0" Y: 25.2" Z: 25.2" Spindle RPM: 14,000 rpm Spindle Taper: CAT 40 Rapid Traverse: 2,362 ipm Cutting Feedrate: 1,968 ipm Maximum Workpiece: ø24.8" x 35.4" Maximum Payload: 880 lbs ATC Capacity: 60 tools Tool to Tool: 0.9 secs Chip to Chip: 2.2 secs Maximum Tool Length (Cat): 16.9" Maximum Tool Diameter: 6.7" Maximum Tool Weight: 26.4 lbs Equipped with: Rigid Tapping Pallet Changer JIS Retention Stud DD Motor Rotary Table Pallet Clamp Confirmation Function Feed Axis Acceleration Auto Grease Supply Device APC Door Interlock Random Pallet Selection 400mm Tapped Hole Pallet Spec (8) Nozzle Coolant Overhead Shower Coolant System (22 Nozzles) Terrace Washing Coolant 300 PSI Through Spindle Coolant and Air Water Soluble Coolant Lift-up Chip Conveyor Secondary Filter for TSC Auto Splash Guard Air Dryer Vision Broken Tool Sensor Auto Fire Extinguish Interface FOR SALE - Please contact David Marban - [email protected] for any questions.
